| Specification |
 Nova Plus 24 |
 Nova Plus 35 |
 Nova Plus 51 |
|---|---|---|---|
| Engraving / Working Area | 23.6″ x 15.7″ x 6.1″ | 35.4″ x 23.6″ x 8.9″ | 51.2″ x 35.4″ x 8.9″ |
| Max Part Size | Pass through closed: 24.2″ x 18.5″ x 6.1″ | Pass through open: 24.0″ x ∞ x 0.8″ | Pass through closed: 36.6″ x 25.6″ x 8.9″ | Pass through open: 37.8″ x ∞ x 0.8″ | Pass through closed: 55.1″ x 40.6″ x 8.9″ | Pass through open: 55.1″ x ∞ x 0.8″ |
| Machine Size（L*W*H） | 44.1″ x 34.1″ x 26.9″ | 59.8″ x 45.3″ x 43.9″ | 74.8" x 55.3″ x 40.9″ |
| Laser Wattage | 60W RF Metal Tube | 60W, 80W RF Metal Tube | 100W, 130W RF Metal Tube |
| Intelligent Memory Capacity | Multiple File Storage up to 1GB | Multiple File Storage up to 1GB | Multiple File Storage up to 1GB |
| Laser Source | CO2 RF Metal Tube, Unmatched laser precision. Average lifespan: 10,000 working hours | CO2 RF Metal Tube, Unmatched laser precision. Average lifespan: 10,000 working hours | CO2 RF Metal Tube, Unmatched laser precision. Average lifespan: 10,000 working hours |
| Electrical Requirements | Standard 110v AC 60Hz Single Phase, dedicated 20A circuit | Standard 110v AC 60Hz Single Phase, dedicated 20A circuit | Standard 110v AC 60Hz Single Phase, dedicated 20A circuit |
| Air Assist | Air pump 5-7 psi included | Air pump 5-7 psi included | Air pump 5-7 psi included |
| Software | LightBurn Software included for two computers; supports Windows, Mac, and Linux | LightBurn Software included for two computers; supports Windows, Mac, and Linux | LightBurn Software included for two computers; supports Windows, Mac, and Linux |
| Red Dot Pointer | Shows where laser will fire; easy positioning | Shows where laser will fire; easy positioning | Shows where laser will fire; easy positioning |
| Camera System | Comes with an over-head camera as standard | Comes with an over-head camera as standard | Comes with an over-head camera as standard |
| Operating Modes | Optimized raster, vector, or combined modes | Optimized raster, vector, or combined modes | Optimized raster, vector, or combined modes |
| Easy Adjustable Home | New home position can be set by hand for items not easily placed in the top corner | New home position can be set by hand for items not easily placed in the top corner | New home position can be set by hand for items not easily placed in the top corner |
| Motion Control System | LeadShine Hybrid-Servo Motors, engraving speeds up to 1,200mm/s (46.8"/second) | LeadShine Hybrid-Servo Motors, engraving speeds up to 1,200mm/s (46.8"/second) | LeadShine Hybrid-Servo Motors, engraving speeds up to 1,200mm/s (46.8"/second) |
| Resolution | Up to 1,000dpi with included 2.5" head or 2,000dpi with 1.5" head | Up to 1,000dpi with included 2.5" head or 2,000dpi with 1.5" head | Up to 1,000dpi with included 2.5" head or 2,000dpi with 1.5" head |
| Safety | Open cover protection, no-air assist protection, heat alarm system | Open cover protection, no-air assist protection, heat alarm system | Open cover protection, no-air assist protection, heat alarm system |
| Auto Focus | Infrared Auto-Focus system for easy focusing | Infrared Auto-Focus system for easy focusing | Infrared Auto-Focus system for easy focusing |
| Cooling | Air Cooling | Air Cooling | Air Cooling |
| Motorized Table | Includes removable honeycomb and solid metal blade (knife-style) bed | Includes removable honeycomb and solid metal blade (knife-style) bed | Includes removable honeycomb and solid metal blade (knife-style) bed |
| Laser Heads | 2.5" Head / Lens included; Optional 1.5", 2.0", and 4.0" heads available | 2.5" Head / Lens included; Optional 1.5", 2.0", and 4.0" heads available | 2.5" Head / Lens included; Optional 1.5", 2.0", and 4.0" heads available |
| TL-Timer™ (Smart Board) | Relay switch controls exhaust and air assist, stops accessories when laser is not working | Relay switch controls exhaust and air assist, stops accessories when laser is not working | Relay switch controls exhaust and air assist, stops accessories when laser is not working |
| Warning Light | Red light means working, and green light means safe | Red light means working, and green light means safe | Red light means working, and green light means safe |
| Warranty | The whole machine is under warranty for two years, and the RF tube is for one year | The whole machine is under warranty for two years, and the RF tube is for one year | The whole machine is under warranty for two years, and the RF tube is for one year |
